Rigid SR-Series Pro Combination 20" LED Light Bar

Item: P916747
0 Read 0 Reviews Write a Review

The SR-Series Pro LED Light Bars from Rigid pack extreme brightness into a wildly low-profile package. As the name implies, the SR-Series Pro Light Ba… Read More

$617.99
Rebate Available! View Details

Product Details

Rigid SR-Series Pro Combination 20" LED Light Bar

The SR-Series Pro LED Light Bars from Rigid pack extreme brightness into a wildly low-profile package. As the name implies, the SR-Series Pro Light Bars use a Single Row of lighting elements that utilize improved LED technology, casting more light output than ever before with up to 111 percent additional raw lumens over older LED technologies. Measuring fewer than 2" from the top of the light to the bottom of the mounting bracket, SR-Series Lights provides a sleek lighting solution with minimal vertical interference.

Ideal for applications where space is limited, the SR-Series consumes very little power while creating tremendous illumination. The sleek design also helps maintain aerodynamic efficiency, cuts wind buffeting, reduces the likelihood of rock/tree damage, and boosts visual appeal. The SR Hyperspot Lights use high-impact polycarbonate and aluminum in their construction, feature 50,000+ hour bulb life, and feature Rigid's branded blacked-out circuit boards for style.

When it comes to LED lighting technology, Rigid Industries "owns the night." Their class-leading product line includes everything from ultra-low amperage rock lights to GPS-enabled "smart" light bars. The company's premier "hybrid" and "specter" optics technologies trickle down to everything that Rigid produces. The result is powerful, American-made optics with up to 40% more lux while using up to 50% less power than the competition.

Specifications:

  • Driving/Spot Combination Light Bar:
    • Size: 30.0 Inch: Light Pattern: Driving/Spot: Amp Draw: 21.64 Watts: 303 Volts: 36 Lumens: 28842
  • Spot/Flood Combination Light Bar:
    • Size: 6.0 Inch: Light Pattern: Spot/Flood: Amp Draw: 3.43 Watts: 48 Volts: 36 Lumens: 4752
    • Size: 10.0 Inch: Light Pattern: Spot/Flood: Amp Draw: 4.29 Watts: 60 Volts: 36 Lumens: 7920
    • Size: 20.0 Inch: Light Pattern: Spot/Flood: Amp Draw: 8.5 Watts: 119 Volts: 36 Lumens: 15840
    • Size: 30.0 Inch: Light Pattern: Spot/Flood: Amp Draw: 11.43 Watts: 160 Volts: 36 Lumens: 18810
    • Size: 40.0 Inch: Light Pattern: Spot/Flood: Amp Draw: 18.5 Watts: 259 Volts: 36 Lumens: 25080
    • Size: 50.0 Inch: Light Pattern: Spot/Flood: Amp Draw: 20.71 Watts: 290 Volts: 36 Lumens: 31350

Includes:

  • SR-Series Light Bar
  • Mounting hardware
  • Wiring harness

Features:

  • Unique combination beam patterns
  • 50,000+ hour lifespan
  • 9-36 volt DC capacity
  • Durable UV-resistant powder coated finish
  • Aluminum alloy construction
  • Integrated thermal management
  • Impact resistant polycarbonate lens
  • Over/under voltage protection
  • RFI/EMI protection
  • Reverse polarity protection
  • RoHS compliant
  • IP69K compliant against dust/water ingress
  • Pressure equalizing vent
  • Operating temp -40 to 145 degrees F
  • SAE J575 compliant against shock/vibration
  • Limited lifetime warranty
  • For off-road use only
Made in the USA
Product Style RevZilla Item # Store Sku MFR. Product # Availability
Product Style 20" / Spot/Flood RevZilla Item #10065817 Store Sku MFR. Product #920314 AvailabilityIn Stock: Ships within 24 hours
Fitment Notes & Exceptions
This is a universal fit part; it may or may not fit without modification.
