Fox Factory Performance Elite Series 2.5 RC Shocks Polaris RZR Pro XP 4 2020-2024

Fox Factory Performance Elite Series 2.5 RC Shocks Polaris RZR Pro XP 4

Performance Elite shocks enhance durability and offer significant adjustability, specifically engineered for your UTV or Side-by-Side vehicle. With these shocks, you can confidently tackle any terrain, thanks to the 7/8” hard chromed shaft and redundant seal pack designed for harsh environments and built for a lifetime of use. Adjust the shock damping to match the terrain and your riding style using the Dual Speed Compression (DSC) settings. Optimize traction with wide-range rebound adjustments and set your ride height with the preload collar.

The 2.5-inch diameter aluminum bodies efficiently dissipate heat and increase internal oil volume, providing better damping control through FOX’s race-developed high-flow pistons. The piggyback reservoir boosts oil capacity and features an internal floating piston to separate the nitrogen charge from the shock oil. Bottom-out control (BOC) offers additional compression damping during hard impacts, increasing damping force by up to 30 percent in the final 25 percent of travel. Enjoy a smooth ride with enhanced small bump compliance while maintaining enough damping capacity to absorb heavy impacts.

FOX Performance Elite Series 2.5 shocks deliver the versatility to excel in any terrain and cater to your ride preference, transforming the dynamic of your vehicle with their bolt-on design.

Features:

• Sold as a pair
• Piggyback reservoir
• 7/8” hard-chromed shaft
• Redundant seal pack
• Dual-Speed Compression (DSC)
• 2.5” Aluminum body
• Bottom-out control (BOC)
• BOC increases damping force up to 30 percent through the final 25 percent of travel
• PTFE-lined spherical bearings
• Fully re-buildable and re-valvable
• Wide-range rebound

Adjustments / Technical Information:

• Front Extended Length: 27.50
• Front Compressed Length: 18.95
• Front Travel: 8.55
• Rear Extended Length: 39.00
• Rear Compressed Length: 25.45
• Rear Travel: 13.55
• Top Mount: Eyelet
• Bottom Mount: Eyelet
• Reservoir: Piggyback

Note: Replaces Fox Factory Part Number: N/A
